Application
Concrete reinforcing wire mesh is considered as a new, efficient and high-quality reinforced construction mesh. It is widely used in residential buildings, roofs, walls, terraces, concrete pavements, deck pavement, airport pavement, tunnel lining, concrete pipes, industrial and civil buildings.
Concrete reinforcing wire mesh is made of cold-drawn steel wire, cold-rolled ribbed steel wires(CRB550) or hot-rolled ribbed steel wires (HRB400). Its diameter and length can be the same or different, and the top and side faces are rectangular or square.
SpecificationsDiameter (mm) | 3mm-16mm | ||
Reinforcement Spacing(mm) | Longitudinal wire | 100-200mm | |
Cross wire | 30-1000mm | ||
Sheet Size | Length | 2-12m | |
Width | 1-3m | ||
Mechanical and Process Property | Meet "GB/T1499.3-2002"Standard; AS/NZS 4671; 2001,BS 4483:2005,A185-02 | ||
Special specifications can be customized. |
Concrete reinforcing wire mesh is suitable for large concrete projects. Our mesh has regular size, strong grid stiffness and high flexibility. When pouring concrete, reinforcing bar is not easy to twist and slide. So we can easily control the thickness of concrete and improve the quality of engineering. Concrete reinforcing wire mesh can bring us economic benefits.
Advantage
It can save more than 33% steel and reduce 10%-30% cost.
It can increase construction speed, and it can be reduced by about 80%.
It can improve the quality of structure. It make concrete bonding reliable, increases tensile strength and prevents cracks. The bonding strength of smooth reinforcing bar is increased by more than three times. The integrity is good, the deviation is small and the crack resistance is over 75%.
Index
concrete wire mesh / steel reinforcement mesh / ribbed steel bar mesh / concrete welded reinforcing mesh / ribbed weld mesh
