Material: | stainless steel SUS: 304, 304L, 316, 316L |
Wire rope diameter: | commonly used is 1.2mm(3/64"), 1.6mm(1/16") and 2.0mm(5/64") |
Structure: | adopting the structure of wire rope for the 7 x 7 rope |
Mesh size: | the mesh used 20 x 20mm(4/5" x 4/5"), 25.4 x 25.4(1" x 1") 38 x 38mm(1.5" x 1.5") and 51 x 51 mm(2" x 2") |
Sheet Size: | can be produced according to customer's requirements(Standard sheet size: 20m x 8m) |
Aviary Mesh, bird netting | ||||
ID | inch | mm | inch | mm |
HM-1220M | 3/64 | 1.2 | 4/5" x 4/5" | 20 x 20 |
HM-1225M | 3/64 | 1.2 | 1" x 1" | 25.4 x 25.4 |
HM-1625M | 1/16 | 1.6 | 1" x 1" | 25.4 x 25.4 |
HM-1638M | 1/16 | 1.6 | 1.5" x 1.5" | 38 x 38 |
HM-2050M | 5/64 | 2.0 | 2" x 2" | 51 x 51 |
Index
Aviary Mesh, bird mesh screen, large bird cage
