This product has been discontinued and removed from our shelves.
Material: Inconel 600 (N06600), Inconel 601 (N06601), Inconel 625 (N06625), Inconel 718 (N07718), Inconel X-750 (N07750)
Mesh Count: 2-200
Weaving: Plain weave, Twill weave
Features of Inconel Wire Mesh:
Inconel wire mesh is non-magnetic and features a great oxidation resistance and high temperature resistance, excellent resistance to corrosion and cracking under normal or high temperature conditions and great mechanical properties.
Grade | C | Cr | Cu | Fe | Mn | Ni | S | Si |
Inconel 600 | 0.15 | 14 - 17 | 0.5 | 6 - 10 | 1.0 | 72.0 | 0.015 | 0.5 |
Grade | C | Cr | Cu | Fe | Mn | Ni | S | Si | Al |
Inconel 601 | 0.1 | 21 - 25 | 1.0 | Rem | 1.0 | 58 - 63 | 0.015 | 0.5 | 1.0 - 1.7 |
Grade | C | Cr | Fe | Mn | Ni | S | Si | Al | Cb | Mo | P | Ti |
Inconel 625 | 0.1 | 20 - 23 | 5.0 | 0.5 | Rem | 0.15 | 0.5 | 0.4 | 3.15 - 4.15 | 8 - 10 | 0.015 | 0.4 |
Grade | C | Cr | Cu | Fe | Mn | Ni | S | Si | Al | Cb | Mo | P | Ti | B | C | Co |
Inconel 718 | 0.08 | 17-21 | 0.3 | Rem | 0.035 | 50 - 55 | 0.015 | 0.35 | 0.2 - 0.8 | 4.75- 5.50 | 2.8 - 3.3 | 0.015 | 0.65- 1.15 | 0.006 | 0.08 | 1.0 |
Grade |
C | Cr | Cu | Fe | Mn | Ni | S | Si | Al | Cb | Ti |
Inconel 750 | 0.08 | 14 –17 | 0.5 | 5 – 9 | 1 | 70 | 0.01 | 0.5 | 0.4 – 1 | 0.7 – 1.2 | 2.0 – 2.6 |
Applications of Inconel Wire Mesh:
Inconel wire mesh can be used in petrochemical, aerospace industry, hydropower, nuclear power, oil refining and shipbuilding, chemical, machinery manufacturing industries.
